Introduction The quality of the electric energy is influenced by the activity of the manufacturer, the transmission and distribution provider, the supplier as well as the electric power consumer activity.
#Mathscript node labview 2015 full#
Using the software application developed in LabVIEW, full quality analysis of electric energy can be done at the user's premises.ġ. The software application enables creation of customized reports with varying ease of use and flexibility.
Based on the data obtained from the measurements and using the interface created in LabVIEW, it was possible to carry out the analysis of the average hourly consumption, the power factor, the wave forms of the current and voltage, the analysis of the current and voltage harmonics. A software application was made to allow reading of files and processing them (creation of data tables and charts). The data processing was achieved using LabVIEW software in terms of the two types of quality indicators. Quality indicators of electric energy, depending on the place of occurrence of disturbances are indicators of primary and secondary quality indicators.
Transients occur at this limiting point, with negative effects on the consumer, as well as on the electric power supply network. The measurements were carried in the power supply point where the quality of the electric energy is influenced by the activity of the manufacturer, the transmission and distribution provider, the supplier as well as the electric power consumer activity.
This paper presents a case study for monitoring the quality of electric energy in an industrial manufacturer of technical rubber and reclaimed rubber products.
